Virtual Switching System: A Switching Technology

Virtual Switching System: VSS is a Cloud Light network gadget virtualization technology that pools multiple Cisco Catalyst 6500 Series Switches into one virtual transfer, growing operational efficiency, boosting nonstop communications, and scaling machine bandwidth ability to one.4 Tbsp. At the initial segment, a VSS will permit two physical Cisco Catalyst 6500 Series. The VSS is made up of the following:

Virtual Switching

Members of VSS: Cisco Catalyst 6500 Series Switches (up to two switches with initial release) deployed with the Virtual Switching Supervisor 720 10GE

Virtual switch hyperlink (VSL): 10 Gigabit Ethernet connections (up to eight using EtherChannel) between the participants.

The 10 Gigabit Ethernet connections ought to be one or greater of the modules: Switching Supervisor 720 10GE: 10 Gigabit Ethernet uplink ports
VSS allows unheard of the functionality and availability of campus community by integrating community and systems redundancy into an unmarried node.VSS is Cisco demonstrated layout. It is the Cisco Safe Harbor application examined and authorized. It permits us to

  • Maximize network performance
  • Increase community availability
  • Simplify community architecture
  • Reduce administrative burden
  • Support virtualization
  • Terminology:


VSS1440 refers to the VSS formed by using two Cisco Catalyst 6500 Series Switches with the Switching Supervisor 720-10GE. In a VSS, the information plane and switch cloth with the capability of 720 Gbps of manager engine in each chassis are active at the equal time on each chassis, combining for an energetic 1400-Gbps switching capability in step with VSS. Only one of the digital transfer members has a lively manipulate plane. Both chassis are saved in sync with the inner chassis Stateful Switchover (SSO) mechanism and Nonstop Forwarding (NSF) to provide nonstop verbal exchange even within the event of failure of one of the member supervisor engines.

Stateful SwitchOver(SSO) mechanism:

A VSS uses inter chassis NSF/SSO as the number one mechanism for excessive availability among the 2 chassis. One virtual transfer member chassis will act because the lively virtual switch member might be in a hot standby kingdom for the managed aircraft even as the opposite member. Note that both chassis’ information planes are energetic and subsequently forward visitors at the full combined capability of 1440 Gbps. When one of the virtual transfer participants fails, there is no reconvergence of protocols within the community. The get admission to layer or core layer switches continues to ahead traffic because they handiest come across a hyperlink failure in an EtherChannel package and do not want to reconverge any protocols. No disruption takes place to the site visitors flowing via the VSS. At some stage in switch failure, the VSS mechanism is far superior compared with the traditional model where one switch failure outcomes indeterminist convergence of a couple of manipulating protocols like STP, HSRP, and routing protocol.

Multichassis Ether Channel(MEC):

Multichassis EtherChannel (MEC) is a Layer 2 multipathing technology. This form of EtherChannel permits a linked node to terminate the EtherChannel across the two bodily Cisco Catalyst 6500 Series Switches that make up the VSS, leading to a simplified loop-unfastened Layer 2 topology. Using MEC in VSS topology affects all hyperlinks being active and at the same time offers for a tremendously to be had topology without the dependency of Spanning Tree Protocol. With the creation of 12.2(33)SXI, the digital switching machine helps the most quantity of 512 MECs.

Virtual Switch Link(VSL):

The connection is used for conversation between the 2 chassis. VSLs may be configured with up to 8 hyperlinks among the 2 switches throughout any mixture of line playing cards or supervisor ports to provide an excessive level of redundancy. If VSL connections are lost among the switch individuals leaving each of the contributors up t for a few rare purposes, VSS will transition to the dual lively healing mode. The dual lively nation is detected rapidly (subsecond) via any of the subsequent three methods:

Enhancement to PAgP used in MEC with connecting Cisco switches

L3 Bidirectional Forwarding Detection (BFD) configuration on a directly linked link (except VSL) between transfer members or through an L2 hyperlink via a get right of entry to layer transfer.

L2 Fast-Hello Dual-Active Detection configuration on an at once connected link (except VSL) between transfer individuals (supported with 12.2(33)SXI) In the twin energetic restoration mode, all interfaces except the VSL interfaces are in an operationally close down nation within the formerly active transfer member. The new energetic virtual switch continues to forward site visitors on all links.
Need for VSS: New business requirements challenge the manner of designing a reliable, fast Network Infrastructure. The want for non-forestall conversation is turning into a basic start line for maximum campus networks.

  • High-bandwidth environments
  • Virtualization (VMs)
  • 10Gbps
  • High-availability environments
  • Minimize network downtime
  • Redundant infrastructure
  • Reduction in the number of devices to manage.
  • Deployment regions for VSS:
  • Campus or data center core/distribution layer
  • Data middle get right of entry to (server connectivity)
  • Benefits of VSS:

VSS offers advanced advantages as compared to conventional Layer 2/Layer three network layout. Benefits can be grouped into the following classes:

Reduce administrative burden:1 lively control plane = 1 logical transfer. There may be a 50% discount on the range of switches that ought to be controlled using VSS. Time to correctly put together for a change window may be substantially reduced. Approximately 60% of network disasters are due to human blunders.

Switching System

It Reduces the variety of instances you and I should contact the transfer, and we would reduce community screw-ups

  • Maximize network performance: Double the bandwidth
  • 2 energetic forwarding planes (720Gbps every)
  • 2 x 720Gbps = 1,440Gbps (1.44Tbps)

Increase network availability – Multichassis EtherChannel (MEC) permits us to reduce the wide variety of neighbor adjacencies cast-off SPF, DUAL, and STP calculations within the occasion of a – single hyperlink failure – VSS chassis failure.

Perform IOS and chassis improvements with minimal disruption.

Only one gateway IP address is required in step with VLAN, in place of the 3 IP addresses in step with VLAN used.
